| Input signal |
4~20mA, 2-wire |
| Stroke |
Linear 10~100mm, rotary 30~105° |
| Air supply pressure |
0.14~0.7Mpa |
| Accuracy |
0.5%F.S |
| Hysteresis |
0.2%F.S |
| Dead band |
0.1%F.S |
| Repetitivity |
0.2%F.S |
| Input impedance |
375 Ω/20mA |
| Output characteristics |
Linearity, equal percentage,
quick-open or user-defined |
|
|
|
|
| Ambient temperature limits |
-20~+70°C |
| Ambient humidity limits |
5%~95%RH |
| Atmospheric pressure |
86~106KPa |
| Explosion approval |
Ex ia IIC T4-T6 |
| Explosion proof class |
Intrinsically safe |
| Electrical connections |
M20 X1.5 |
| Air connections |
G 1/4 , NPT1/4 |
| Weight |
2 kg |
| Enclosure rating |
IP65
